| Наименование марки: | FY |
| Номер модели: | FY-CBK-120 |
| МОК: | 1 комплект |
| Условия оплаты: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Способность к поставкам: | 300 комплектов в месяц |
Car AC Hose Crimping Machine Heavy Duty Automotive Ac Crimping Tool
DESCRIPTION
Product Name: AC Hose Crimping Machine
Hose Diameter Range: 6 to 76mm (up to 3 Inch)
Thickness: Super Thickness Design
Included Dies: 15 Dies for Versatile Applications
Crimping Force: Withhold Faster Crimping Force of 650 Tons
Color: Blue
Key Features:
ADVANTAGES
► Advanced control system, high stability and productivity
► Quick die installing, make crimping more easily and save time
► Double use foot pedal, free both of the hand for carrying big or heavy work piece
TECHNICAL DATA
| Model | FY-CBK-120 AC Hose Crimping Machine |
| Crimping Range | 6-76(mm) |
| Crimping Force | 1500(T) |
| Hose Size | 1/4-3(inch) |
| Max. Opening | 158(mm) |
| Die Sets | 15 |
|
The Max Open Tolerance
|
+53mm
|
| System Pressure | 31.5(Mpa) |
| Accuracy | 0.01(mm) |
|
Output Volume Of Pump
|
10L/16L |
| Standard Voltage | 380(V) |
| Motor Power | 5.5(KW) |
| Length | 1000(mm) |
| Width | 800(mm) |
| Height | 1630(mm) |
| Weight |
1250(KG) |
